Column

Type

Size

Nulls

Auto

Default

Children

Parents

Comments

_set_key

int4

mgi_setmember._set_key

mgi_setmember__set_key R

_mgitype_key

int4

acc_mgitype._mgitype_key

mgi_set__mgitype_key R

name

varchar

255

sequencenum

int4

_createdby_key

int4

mgi_user._user_key

mgi_set__createdby_key R

_modifiedby_key

int4

mgi_user._user_key

mgi_set__modifiedby_key R

creation_date

timestamp

29,6

modification_date

timestamp

29,6

Table contained 41 rows at Mon Sep 26 19:11 EDT 2011

Indexes:

Column(s)	Type	Sort	Constraint Name
_set_key	Primary key	Asc	mgi_set_pkey
_set_key	Must be unique	Asc	mgi_set_idx_set_key
_mgitype_key + name + _set_key + sequencenum	Performance	Asc/Asc/Asc/Asc	mgi_set_idx_mgitype_key
name + _mgitype_key + _set_key + sequencenum	Performance	Asc/Asc/Asc/Asc	mgi_set_idx_name
