Gene Expression Image Detail

Reference

Figure

ID

J:170604 Zhang Z, et al., Dev Biol. 2011 Mar 15;351(2):254-65

5

MGI:8190536


Caption

RNA situ hybridization at E10 (left) or E10.25 (right). Arrows indicate the posterior boundary of forelimb or anterior boundary of hindlimb with somite number indicated. Filled arrowheads indicate presence of expression in the hindlimb bud field. Open arrowheads indicate lack of expression in the mutant lateral plate mesoderm at the A-P position corresponding to the nascent hindlimb bud in the control.

Copyright

Reprinted with permission from Elsevier from 10.1016/j.ydbio.2011.01.005 Dev Biol 351: 254-65, Zhang Z; O'Rourke JR; McManus MT; Lewandoski M; Harfe BD; Sun X, The microRNA-processing enzyme Dicer is dispensable for somite segmentation but essential for limb bud positioning. Copyright 2011.

Associated
Assays

Label	Assay & Result Details (Gene Symbol)	Spatial Mapping
A	MGI:8190681 (Axin2)
B	MGI:8190681 (Axin2)
C	MGI:8190681 (Axin2)
D	MGI:8190681 (Axin2)
E	MGI:8190643 (Fgf8)
F	MGI:8190643 (Fgf8)
G	MGI:8190643 (Fgf8)
H	MGI:8190643 (Fgf8)
I	MGI:8190682 (Spry2)
J	MGI:8190682 (Spry2)
K	MGI:8190682 (Spry2)
L	MGI:8190682 (Spry2)
M	MGI:8190683 (Fgf10)
N	MGI:8190683 (Fgf10)
O	MGI:8190683 (Fgf10)
P	MGI:8190683 (Fgf10)
