Gene Expression Data
Assay Details
Assay
Reference: J:122989 Visel A, et al., GenePaint.org: an atlas of gene expression patterns in the mouse embryo. Nucleic Acids Res. 2004 Jan 1;32(Database issue):D552-6
Assay type: RNA in situ
MGI Accession ID: MGI:5422745
Gene symbol: Scaf4
Gene name: SR-related CTD-associated factor 4
Probe: 3E2
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure. These data were downloaded from GenePaint.org on 1/30/12.
Results
Specimen MY279; Specimen C1598: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS22: nervous system Weak Regionally restricted Embryo_C1598_5_2B
TS22: central nervous system Weak Regionally restricted Embryo_C1598_5_2B
TS22: telencephalon Weak Regionally restricted Embryo_C1598_5_2B
TS22: cerebral cortex Weak Regionally restricted Embryo_C1598_5_2B
TS22: neocortex Weak Regionally restricted Embryo_C1598_5_2B
TS22: olfactory cortex Weak Regionally restricted Embryo_C1598_5_2C
TS22: main olfactory bulb Weak Regionally restricted Embryo_C1598_5_2C
TS22: piriform cortex Absent
TS22: hippocampus Weak Regionally restricted Embryo_C1598_5_2B
TS22: basal ganglia Weak Regionally restricted Embryo_C1598_5_1B
TS22: corpus striatum Weak Regionally restricted Embryo_C1598_5_1B Expression was weak in the corpus striatum (lateral ganglionic eminence).
TS22: basal forebrain Absent
TS22: amygdala Weak Regionally restricted Embryo_C1598_5_1B
TS22: telencephalon septum Weak Regionally restricted Embryo_C1598_5_4A
TS22: pallidum Weak Regionally restricted Embryo_C1598_5_2C Expression was weak in the pallidum (medial ganglionic eminence).
TS22: diencephalon Weak Regionally restricted Embryo_C1598_5_4A
TS22: thalamus Weak Regionally restricted Embryo_C1598_5_3B
TS22: hypothalamus Weak Regionally restricted Embryo_C1598_5_4A
TS22: midbrain Weak Regionally restricted Embryo_C1598_5_3C
TS22: pretectum Absent
TS22: superior colliculus Weak Regionally restricted Embryo_C1598_5_3B
TS22: inferior colliculus Weak Regionally restricted Embryo_C1598_5_3C
TS22: midbrain tegmentum Absent
TS22: hindbrain Weak Regionally restricted Embryo_C1598_5_5B
TS22: cerebellum Absent
TS22: pons Weak Regionally restricted Embryo_C1598_5_5B
TS22: medulla oblongata Weak Regionally restricted Embryo_C1598_5_3B
TS22: spinal cord Weak Regionally restricted Embryo_C1598_5_3B
TS22: choroid plexus Absent
TS22: meninges Absent
TS22: peripheral nervous system Weak Regionally restricted Embryo_C1598_5_3A
TS22: cranial ganglion Weak Regionally restricted Embryo_C1598_5_2B
TS22: dorsal root ganglion Weak Regionally restricted Embryo_C1598_5_3A
TS22: eye Weak Regionally restricted Embryo_C1598_5_1A
TS22: retina Weak Regionally restricted Embryo_C1598_5_1A
TS22: lens Absent
TS22: cornea Absent
TS22: optic nerve Weak Regionally restricted Embryo_C1598_5_4C
TS22: nose Weak Regionally restricted Embryo_C1598_5_2C
TS22: olfactory epithelium Weak Regionally restricted Embryo_C1598_5_2C
TS22: ear Weak Regionally restricted Embryo_C1598_5_5A
TS22: inner ear Weak Regionally restricted Embryo_C1598_5_5A
TS22: cochlea Weak Regionally restricted Embryo_C1598_5_5A
TS22: inner ear labyrinth Weak Regionally restricted Embryo_C1598_5_6A
TS22: middle ear Weak Regionally restricted Embryo_C1598_5_1A
TS22: alimentary system Weak Regionally restricted Embryo_C1598_5_5B Expression was weak in the digestive system.
TS22: intestine Weak Regionally restricted Embryo_C1598_5_3A
TS22: salivary gland Weak Regionally restricted Embryo_C1598_5_5B
TS22: tongue Weak Regionally restricted Embryo_C1598_5_3B
TS22: tooth Weak Regionally restricted Embryo_C1598_5_4A
TS22: palatal shelf Weak Regionally restricted Embryo_C1598_5_3A
TS22: esophagus Weak Regionally restricted Embryo_C1598_5_4A
TS22: stomach Weak Regionally restricted Embryo_C1598_5_5B
TS22: liver Weak Regionally restricted Embryo_C1598_5_2A
TS22: respiratory system Weak Regionally restricted Embryo_C1598_5_4A
TS22: pharynx Weak Regionally restricted Embryo_C1598_5_4A
TS22: larynx Weak Regionally restricted Embryo_C1598_5_4A
TS22: trachea Weak Regionally restricted Embryo_C1598_5_4A
TS22: main bronchus Weak Regionally restricted Embryo_C1598_5_4B
TS22: lung Weak Regionally restricted Embryo_C1598_5_3B
TS22: urinary system Moderate Regionally restricted Embryo_C1598_5_4A Expression was detected in the genito-urinary system.
TS22: metanephros Weak Regionally restricted Embryo_C1598_5_5B
TS22: ureter Absent
TS22: bladder Absent
TS22: urethra Weak Regionally restricted Embryo_C1598_5_4A
TS22: reproductive system Moderate Regionally restricted Embryo_C1598_5_4A
TS22: genital tubercle Moderate Regionally restricted Embryo_C1598_5_4A
TS22: gonad Absent
TS22: gland Weak Regionally restricted Embryo_C1598_5_3C Expression was weak in the endocrine system.
TS22: thyroid gland Weak Regionally restricted Embryo_C1598_5_3C
TS22: pituitary gland Weak Regionally restricted Embryo_C1598_5_4A
TS22: pancreas Absent
TS22: adrenal gland Absent
TS22: cardiovascular system Weak Regionally restricted Embryo_C1598_5_3B
TS22: heart Weak Regionally restricted Embryo_C1598_5_3B
TS22: heart atrium Weak Regionally restricted Embryo_C1598_5_4A
TS22: heart ventricle Weak Regionally restricted Embryo_C1598_5_3B
TS22: blood vessel Absent
TS22: hemolymphoid system Weak Regionally restricted Embryo_C1598_5_4B Expression was weak in the immune system.
TS22: spleen primordium Absent
TS22: thymus primordium Weak Regionally restricted Embryo_C1598_5_4B
TS22: appendicular skeleton Weak Regionally restricted Embryo_C1598_5_2C Expression was weak in the skeleton (limbs, shoulder, hip).
TS22: musculature Absent
TS22: face Weak Regionally restricted Embryo_C1598_5_2B Expression was weak in the face/soft tissues.
TS22: facial bone primordium Absent
TS22: cranium Absent Expression was not detected in the skull (base and vault).
TS22: axial skeleton Absent
TS22: tail Weak Regionally restricted Embryo_C1598_5_4A
TS22: forelimb Moderate Regionally restricted Embryo_C1598_5_6A
TS22: hindlimb Moderate Regionally restricted Embryo_C1598_5_5C
TS22: integumental system Moderate Regionally restricted Embryo_C1598_5_4A
TS22: skin Moderate Regionally restricted Embryo_C1598_5_4A
TS22: hair Weak Regionally restricted Embryo_C1598_5_1B
TS22: vibrissa follicle Weak Regionally restricted Embryo_C1598_5_1B Expression was weak in whisker follicle.
