Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4825536
Gene symbol: Igf2bp1
Gene name: insulin-like growth factor 2 mRNA binding protein 1
Probe: IMAGE clone 805632
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_000116_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lens capsule Weak Uniform euxassay_000116_01
Specimen euxassay_000116_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lens Weak Uniform euxassay_000116_02
TS23: lens capsule Weak Uniform euxassay_000116_02
TS23: retina Weak Regionally restricted euxassay_000116_02
Specimen euxassay_000116_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: retina Weak Regionally restricted euxassay_000116_03
Specimen euxassay_000116_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: retina Weak Regionally restricted euxassay_000116_04
Specimen euxassay_000116_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: foot mesenchyme Strong Regionally restricted euxassay_000116_08
Specimen euxassay_000116_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: foot mesenchyme Strong Regionally restricted euxassay_000116_09
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_09
TS23: metanephros Moderate Uniform euxassay_000116_09
Specimen euxassay_000116_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: foot mesenchyme Strong Regionally restricted euxassay_000116_10
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_10
TS23: metanephros Moderate Regionally restricted euxassay_000116_10
Specimen euxassay_000116_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_11
TS23: renal cortex Moderate Regionally restricted euxassay_000116_11
Specimen euxassay_000116_13: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: renal cortex Strong Regionally restricted euxassay_000116_13 lumen
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_13
Specimen euxassay_000116_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_14
Specimen euxassay_000116_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_15
Specimen euxassay_000116_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_16
Specimen euxassay_000116_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_17
Specimen euxassay_000116_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_18
Specimen euxassay_000116_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_19
TS23: metanephros Moderate Regionally restricted euxassay_000116_19
Specimen euxassay_000116_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_20
TS23: metanephros Moderate Regionally restricted euxassay_000116_20
Specimen euxassay_000116_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: physiological umbilical hernia Strong Regionally restricted euxassay_000116_21
TS23: metanephros Moderate Regionally restricted euxassay_000116_21
Specimen euxassay_000116_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: metanephros Moderate Regionally restricted euxassay_000116_22
TS23: physiological umbilical hernia Moderate Regionally restricted euxassay_000116_22
Specimen euxassay_000116_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: metanephros Moderate Regionally restricted euxassay_000116_23
Specimen euxassay_000116_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: metanephros Moderate Uniform euxassay_000116_24
